1.0 ton/1.2 ton walkie economical electric pallet stacker
Print this Page
Bookmark this
Inquiry product
E-mail Us
-
Product name:Economiacal electric pallet stacker
-
Load capacity:1000kg/1200kg
-
Lifting height:1.6m/2.5m/3m/4m
-
Controller:CURTIS
-
DC Motor
-
80Ah
-
Free Maintenance battery
-
Charger
-
2-stage mast
-
0.75kw(driving) 2.2kw(lifting)
Features
1: Smart body, with attractive appearance. High-strength frame designed for tough pallet handling tasks.
2: Lower consumption, Lower service cost, while higher performance.
3: 24V/65AH (80AH optional) maintenance free battery contributes to strong power and easier operation.
4: Compact structure and reasonable layouts provides steadiness and durability during operation.
Performance
1: Ergonomically designed and built Handle is increasing your comfort during operation. Dust proof and sealing structure prevent it from dust pollution damages and improve service life.
2: Intelligent and modular controlling system ensures the steadiness and safety for walking, lifting, lowering and braking.
3: Handle is utilized for easier operation and less turning radius, suitable for confined space and narrow aisle.
Safety
1: The Anti-Reverse safety button mounted at the top of the handle reverses the truck direction to prevent the operator from being caught between the truck and the obstacle on unexpected occasions.
2: Intelligent controller takes protection measures in case of over voltage, low voltage, over current, over temperature and short circuit occasions.
3: Especially innovated speed deceleration system automatically reduces the travel speed when turning and greatly improved the loading stability, avoiding possibility of load tipping over and making operate safer.(Optional)
Serviceability
1: Self-Diagnostics provided direct fault code readout during operation and start up, which is ease of service and maintenance.
2: 24V/65AH (80AH optional) maintenance free battery contributes to strong power and easier operation, meeting most requirements for light and medium duty applications
3: Built-in charger practically eliminates contamination entry, which can result in failure.
Packaging & Delivery
Packaging Details: International packing way, packed with thick plastic film.
Delivery Detail: 25 days after the advance payment.
Youtube:https://www.youtube.com/watch?v=xbQsuvKa14A
|
Characteristics |
|
|
|
1.1 |
Manufacturer |
NOELIFT |
|
1.2 |
Model |
ES12M |
|
1.4 |
Operate Type |
Walkie |
|
1.5 |
Load Capacity |
1200 |
|
1.6 |
Load Center |
500 |
|
1.9 |
Wheelbase |
1208 |
|
Weight |
|
|
|
2.1 |
Service Weight(Incl. Battery) |
567/642/666/690 |
|
Wheels,Chassis |
|
|
|
3.1 |
Tyre Type |
PU |
|
3.2 |
Tyre Size,Drive Wheels |
Φ220x80 |
|
3.3 |
Tyre Size,Load Wheels |
Φ80x60 |
|
3.4 |
Tyre Size,Balance Wheels |
Φ115x55 |
|
3.5 |
Wheels,Numbers(x= drive wheel) |
1+1/4 |
|
Dimensions |
|
|
|
4.2 |
Height,Mast lowered |
2150/1785/2035/2185 |
|
4.3 |
Free Lift |
－ |
|
4.4 |
Lift Height |
1600/2500/3000/3300 |
|
4.5 |
Height,Mast Extended |
2150/3005/3505/3805 |
|
4.9 |
Height of tiller arm,Min/Max |
538/1160 |
|
4.15 |
Fork Height, Lowered |
85 |
|
4.19 |
Overall Length |
1716 |
|
4.21 |
Overall Width |
800 |
|
4.22 |
Fork Dimension |
1150x160x50 |
|
4.25 |
Outside Fork Width |
560 |
|
4.32 |
Ground Clearance |
30 |
|
4.33 |
AST,1000X1200 pallet crossways |
2225 |
|
4.34 |
AST,800X1200 pallet crossways |
2150 |
|
4.35 |
Outer Turning Radius |
1378 |
|
Performance |
|
|
|
5.1 |
Travel Speed, Laden/Unladen |
5.0/5.5 |
|
5.2 |
Lifting Speed, Laden/Unladen |
0.12/0.22 |
|
5.3 |
Lowering Speed, Laden/Unladen |
0.12/0.11 |
|
5.8 |
Max Gradeability, Laden/Unladen |
3.0/10.0 |
|
Drive |
|
|
|
6.1 |
Drive Motor Rating S2 60Min |
0.75DC |
|
6.2 |
Lifting Motor Rating S3 15% |
2.20DC |
|
6.4 |
Battery Voltage/Capacity(5h) |
24/100 |
|
Others |
|
|
|
7.1 |
Controller |
CURTIS |
|
7.2 |
Service Brake |
REGENERATING |
|
7.3 |
Parking Brake |
Electromagnetic |
