Fork-over electric pallet stacker 1-2.5 ton

ELECTRIC PALLET STACKER FEATURE Rated load capacity:1000-2500kg, Max. lift height: 4500mm, used for single face pallet; 1. With EPS steering system, easier to operation; 2. Electronic type braking; 3.To use intelligent charger, auto analysis the re...

Send Inquiry

Features

ELECTRIC PALLET STACKER FEATURE Rated load capacity:1000-2500kg, Max. lift height: 4500mm, used for single face pallet;

1. With EPS steering system, easier to operation;

2. Electronic type braking;

3.To use intelligent charger, auto analysis the residual energy and optimizing the charging process, without manual operation and extend the battery working life effectively;

4. Speed limited for high position, to avoid the possibility of products' overturning when high speed in high position;

5. High strength overhead guard to protect the operator.

FORK-OVER ELECTRIC PALLET STACKER SPECIFICATIONS

1	Description		Fork-over electric pallet stacker
2	Model		TB10	TB15	TB20		TB25
3	Model		-16	25	16		1600
4	Load capacity	kg	1000	1500	2000		1500
5	Load center	mm	500
6	Max.lifting Height	mm	1600	2500		1600	1600
7	Free lift	mm	0
8	Wheel type		Polyurethane solid tire
9	Pedal length	mm	500	500	500		500
10	Fork size (L*W)mm	mm	1150*190	1150*190	1150*190		1150*190
11	Width of forks (aptotic)	mm	680	680	680		680
12	Overall length(the pedal is closed)	mm	2023	2023	2023		2023
13	Over width	mm	850	850	850		850
14	Overall height(mast closed )	mm	2080	1795	2080		2080
15	Overall height fork raised (with backrest)	mm	2080	2970	2080		2080
16	Outside turning radius	mm	1720	1720	1720		1720
17	Min.intersecting aisle(1000*1200 pallet)	mm	2450	2450	2450		2450
18	Grade ability	%	8-10	8-10	8-10		8-10
19	Total weight (with battery)	Kg	880	940	950		980
20	Battery	V/Ah	24/210
21	Charger	V/A	24/43
22	Driving motor	Kw	1.2	1.2	1.2		1.2
